16 ER19WTF PR1115 Grade PVD Carbide, Indexable Threading Insert
Laydown Threading Insert; 16 ER19WTF PVD CBD PR1115 ; 19 TPI × 3/8″ IC ; | G | ; Carbide ; TiAlN
| Thread Standard | G | Applicable Material | Stainless Steel | Super-Alloys / Titanium |
| Inscribed Circle Diameter (IC) | 3/8″ | Insert Style | 16ER |
| Threads per Inch (TPI) | 19 | Mounting Style | Clamp | Screw |
| Corner Radius (RE) | 0.006″ | Cutting Direction (HAND) | Right Hand |
| Insert Thickness (S) | 0.145″ | Chip Breaker Type | TF |
| Grade | PR1115 | Cutting Item Count (CICT) | 3 |
| Coating | TiAlN | Series/List # | LDT |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Cutting Position | External | Hole Diameter | 0.1575″ |
| Application | External Threading | Profile Included Angle (PNA) | 55 Degrees |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
.081
