Electrical Connectors - TV10–250MD-XV–12–10 Disconnect
| Type | Male | Wire Range | 12-10 AWG |
| Insulation Type | PVC | Maximum Temperature | 90°C (194°F) |
| Color | Yellow | Maximum Voltage | 300 V |
Product Features
| Remarks | •Rigid polyvinyl chloride (PVC) insulation for wire range from #22 to #10 •Female is tin plated brass with rolled edge design for maximum spring •Male is pure copper tab, with zinc chromate for greater corrosion resistance •UL listed 0 7B07, CSA approved ? AP98720 to 90°C (194°F) maximum •600V Maximum building wire (1000V max. in fixtures and signs) | Country of Origin | China |
Shipping Info
Package Weight
0.004
