20″ × 1″ × 8″ 86A Cylindrical Wheel Type 01 Straight 60 Grit Aluminum Oxide
| Diameter | 20″ | Hardness | J |
| Width | 1″ | Wheel Type | Type 1 |
| Arbor Hole | 8″ | Color | Brown |
| Abrasive Material | Aluminum Oxide | Bond Type | Vitrified |
| Grit | 60 | Maximum RPM | 1,625 |
| Grade | Medium | Specification | 86A60-J8V127 |
| Thickness | 1″ | Standard Pack | 1 |
Product Features
| Remarks | •Premium abrasive and superior bond system produce high grinding G-Ratios (metal removal/wheel wear) for increased productivity •Less wheel dressing means lower abrasive costs •Hold form for better part geometry •Engineered for easy use, grind cycles do not need to be altered, no special operator training is needed •Better choice for longer wheel life •Cylindrical wheels are used most often when the part is held between centers and in chucks. There are three methods of cylindrical grinding: plunge, traverse, and angular. Plunge grinding wheels are thrust or plunged into the part, traverse grinding wheels move across the part, and angular grinding wheels contact the part at an angle. | Country of Origin | USA |
Shipping Info
Package Weight
25.5
